Pipe Support Engineering & Thermal Stress Analysis

Our Project Engineer will coordinate with your fabricator and the EOR/Owner to acquire all the relevant plans and structural drawings of the building/structure. If required, they will visit the site to assess the site conditions and prepare a preliminary design after talking to your foreman. Some of the software we use to design Pipe Supports are Mathcad, AutoCAD and SolidWorks. We use AutoPipe for thermal stress analysis. By company policy, our Drafting team will create 3d isometric view of the pipe supports along with regular 2d drawings so that your field personnel get a good visualization of the work to be done.
